Wago 880-687 green-yellow 3 conductor protective conductor terminal

Wago 880-687 green-yellow 3 conductor protective conductor terminal

In stock

SKU: 519333

Price on request

€4.99

€0

Into a basketIn the basketGo

Overview

3-conductor protective conductor terminal, 4 mm², side and center labeling, for mounting rail 35 x 15 and 35 x 7.5, CAGE CLAMP®, 4.00 mm², green-yellow

Property	Value
Operating temperature:	105 °C
Connectable conductor cross-section, single-wire:	0.08 to 4 mm²
Connectable conductor cross-section, stranded:	0.08 to 4 mm²
Connectable conductor cross-section, stranded without wire end ferrule:	0.08 to 4 mm²
Connectable conductor cross-section, finely stranded with wire end ferrule:	0.08 to 2.5 mm²
PEN function possible:	yes
Design of electrical connection 1:	spring-loaded connection
Design of electrical connection 2:	spring-loaded connection
Number of levels:	1
Number of terminal points per level:	3
Color:	green/yellow
Mounting type:	DIN rail TH35
Flammability class of the insulating material according to UL 94:	V0
End plate required:	yes
Material of the insulating body:	Thermoplastic

Characteristics

HAB880-687 green-yellow

Minimal order100 pcs

Manufacturer

HAN880-687

GTIN4045454084769

Connectable conductor cross-section solid0.08 to 4 mm²

Connectable conductor cross-section stranded0.08 to 4 mm²

Operating temperatur105°C

Flammability class of the insulating material according to UL 94V0

Color

Mounting typeDIN rail TH35
