Wago 289-549 Sub-Min-D pin strip 50-pin transfer module

Wago 289-549 Sub-Min-D pin strip 50-pin transfer module

In stock

SKU: 520175

Price on request

€80.57

€0

Into a basketIn the basketGo

Overview

Transfer module, Sub-Min-D, pin strip, 50-pin, mating connector with solder connection, vertical plug-in direction, PCB terminals, 2-row, in mounting base, 2, 50 mm²

Property	Value
Depth:	85 mm
Mounting type:	DIN rail TH35
Design of electrical connection, field side:	Spring-loaded connection
Degree of pollution:	2
Rated voltage:	125 V
Rated current:	2 A
Design of electrical connection, control side:	D-Sub
Width:	94 mm
Number of poles:	50
Height:	34 mm

Characteristics

HAB289-549 Sub-Min-D pin header 50-pin

Manufacturer

HAN289-549

GTIN4045454322779

Rated voltage125V

Rated current2 A

Width94 mm

Height34 mm

Mounting typeDIN rail TH35

Number of poles50

Depth85 mm

Degree of contamination2
