Wago 289-555 Sub-Min-D socket strip 9-pin transfer module

Wago 289-555 Sub-Min-D socket strip 9-pin transfer module

In stock

SKU: 519530

Price on request

€39.18

€0

Into a basketIn the basketGo

Overview

Transfer module, Sub-Min-D, socket strip, 9-pin, mating connector with solder connection, vertical plug-in direction, PCB terminals, 2-row, in mounting base, 2.50 mm²

Property	Value
Depth:	85 mm
Mounting type:	DIN rail TH35
Design of electrical connection, field side:	Spring-loaded connection
Degree of pollution:	2
Rated voltage:	125 V
Rated current:	2 A
Design of electrical connection, control side:	D-Sub
Width:	38 mm
Number of poles:	9
Height:	34 mm

Characteristics

HAB289-555 Sub-Min-D socket strip 9-pin

Manufacturer

HAN289-555

GTIN4045454371180

Rated voltage125V

Rated current2 A

Width38 mm

Height34 mm

Mounting typeDIN rail TH35

Number of poles9

Depth85 mm

Degree of contamination2
