Wago 289-728 transfer module

Wago 289-728 transfer module

In stock

SKU: 523020

Price on request

€85.79

€0

Into a basketIn the basketGo

Overview

Transfer module, Sub-Min-D, socket strip, 37-pin, double-deck PCB terminals, in mounting base, with soldering point, 2.50 mm²

Property	Value
Depth:	85 mm
Mounting type:	DIN rail TH35
Design of electrical connection, field side:	Spring-loaded connection
Pollution level:	2
Rated voltage:	125 V
Rated current:	2 A
Design of electrical connection, control side:	D-Sub
Width:	99.5 mm
Number of poles:	37
Height:	48 mm

Characteristics

HAB289-728

Manufacturer

HAN289-728

GTIN4045454609801

Rated voltage125V

Rated current2 A

Width99.5 mm

Height48 mm

Mounting typeDIN rail TH35

Number of poles37

Depth85 mm

Degree of contamination2
