Wago 2002-7211 TOPJOB S 2.5qmm grey 2 conductor equipotential bonding terminal

Wago 2002-7211 TOPJOB S 2.5qmm grey 2 conductor equipotential bonding terminal

In stock

SKU: 520028

Price on request

€3.12

€0

Into a basketIn the basketGo

Overview

2-conductor equipotential bonding terminal, 2.5 mm², Push-in CAGE CLAMP®, 2.50 mm², gray

Property	Value
Connectable conductor cross-section, finely stranded without wire end ferrule:	0.25 to 4 mm²
Operating temperature:	105 °C
Connectable conductor cross-section, single-wire:	0.75 to 4 mm²
Connectable conductor cross-section, multi-wire:	0.25 to 2.5 mm²
Connectable conductor cross-section, finely stranded with wire end ferrule:	0.75 to 2.5 mm²
Design of the electrical connection:	Spring-loaded connection
Rated current In:	32 A
Rated voltage:	250 V
Number of terminal points:	2
Mounting type:	DIN rail TH35
Connection plate required:	yes
Color:	other
Suitable for N busbar:	3x10 mm
Flammability class of the insulating material according to UL 94:	V0
Material of the insulating body:	Thermoplastic

Characteristics

HAB2002-7211 TOPJOB S 2,5qmm grey

Minimal order50 pcs

Manufacturer

HAN2002-7211

GTIN4045454802301

Connectable conductor cross-section solid0.75 to 4 mm²

Connectable conductor cross-section stranded0.25 to 2.5 mm²

Design of the electrical connectionSpring-loaded connection

Rated voltage250V

Rated current In32 A

Operating temperatur105°C

Flammability class of the insulating material according to UL 94V0

Color

Mounting typeDIN rail TH35

Wago 2002-7211 TOPJOB S 2.5qmm grey 2 conductor equipotential bonding terminal

Wago 2002-7211 TOPJOB S 2.5qmm grey 2 conductor equipotential bonding terminal

Price on request

€3.12

€0

Into a basketIn the basketGo
