Wago 281-612/281-418 fuse terminal block series 281

In stock

SKU: 522616

Price on request

€15.10

€0

Overview

2-conductor fuse terminal, with pivoting fuse holder, with defect indication via glow lamp, 120 V, for mounting rail 35 x 15 and 35 x 7, 5, 4 mm², CAGE CLAMP®, 4, 00 mm², gray

Property	Value
Connectable conductor cross-section, single-wire:	0.08 to 4 mm²
Connectable conductor cross-section, stranded:	0.08 to 4 mm²
Connectable conductor cross-section, stranded without wire end ferrule:	0.08 to 4 mm²
Connectable conductor cross-section, fine-stranded with wire end ferrule:	0.25 to 2.5 mm²
Operating temperature:	105 °C
Rated current In:	10 A
Design of the fuse insert:	G-fuse 5x25 mm
Design of the fuse holder:	pivoting
Type of display element for the defect display:	Glow lamp
Supply voltage for the Defect indication:	120 V
Voltage type for the defect indication:	AC/DC
Rated voltage:	800 V
Design of electrical connection 1:	Spring-loaded connection
Design of electrical connection 2:	Spring-loaded connection
Number of levels:	1
Mounting type:	DIN rail TH35
Color:	gray
End plate required:	yes
Flammability class of the insulating material according to UL 94:	V0
Material of the insulating body:	Thermoplastic
