Eaton DILA-XHIR22 4-pole EHS module auxiliary contactor, 139580

In stock
SKU: 474247
€32.76
Into a basketIn the basketGo

Overview

Auxiliary switch module, with positively guided contacts, (excluding microswitches), switching elements according to EN 50005, combinations of version E correspond to EN 50011 and are to be preferred., DC operated contactors DILA (C) -22 may only be combined with 2-pole auxiliary switches., Function: for standard applications, for electronic applications, 4-pole, Connection technology: screw terminals, Rated operating current AC-15 220 V 230 V 240 V: Ie= 4 A, Rated operating current AC-15 380 V 400 V 415 V: Ie= 4 A, Contacts N/O = normally open: 2 N/O (1 N/O via microswitch for electronic applications), Contacts N/C = normally closed: 2 N/C (1 N/C via microswitch for electronic applications), Mounting type: front mounting, can be used for: DILA (C)., DILM (C) 7., DILM (C) 9., DILM (C) 12., DILM (C) 15., DILM (C) 17., DILM (C) 25., DILM (C) 32., DILM38., DILMP20., DILMP32., DILMP45., DILL., DILMF8., DILMF11., DILMF14., DILMF17., DILMF25., DILMF32., Design: Surface-mounted auxiliary switch, Notes: Conventional auxiliary switches normally open 63/64 and normally closed 71/72 with positively guided contacts, in accordance with IEC/EN 60947-5-1 Appendix L, within the auxiliary switch modules and for the integrated auxiliary switches of the DILM 7 - DILM32 (not microswitches), All auxiliary normally closed contacts (also microswitch normally closed 81/82) can be used as a mirror contact according to IEC/EN 60947-4-1 Annex F (not late opening), code number/design of the combinations code number: 51E, 42, 33

PropertyValue
Number of contacts as normally open:2
Number of contacts as normally closed:2
Mounting type:Front mounting
Type of electrical connection:Screw connection
Design:plug-in
Rated operating current Ie at AC-15, 230 V:4 A
Socket:without

Characteristics

HABDILA-XHIR22 4-pin EHS module
Minimal order5 pieces
ManufacturerEaton
HAN139580
GTIN4015081363582
Number of contacts as normally open2
Number of contacts as opener2
VersionAttachable
Design of the electrical connectionScrew connection
Rated operating current Ie at AC-15, 230 V4 A
VersionWithout
Mounting typeFront mounting
Eaton DILA-XHIR22 4-pole EHS module auxiliary contactor, 139580
Eaton DILA-XHIR22 4-pole EHS module auxiliary contactor, 139580
€32.76
Into a basketIn the basketGo
