Optional accessories for the NZM circuit breaker series offer an extensive portfolio of application options for worldwide use. Installation is flexible and simple thanks to modular function groups. Notes: Pulse current sensitive. Rated control supply voltage: Us = 230VAC (50/60 Hz). Auxiliary switch (1 changeover contact) integrated. Through-hole transformer must be ordered separately. Not UL/CSA approved. Fault current and delay time adjustable. Fault current pre-warning by flashing red LED. Adjustable fault current: 0.03, 0.1, 0.3, 0.5, 1, 3, 5 A. Adjustable delay time: 0.02, 0.1, 0.3, 0.5, 1, 3, 5 s. Can be used for: NZM1, NZM1-4, N1, N1-4, NZM2, NZM2-4, N2, N2-4, NZM3, NZM3-4, N3, N3-4, NZM4, NZM4-4, N4-4
| Property | Value |
| Max. response delay time: | 5000 ms |
| Max. rated operating voltage Ue: | 276 V |
| Delay time adjustable: | yes |
| Rated control supply voltage Us at AC 50 Hz: | 184 to 276 V |
| Rated control supply voltage Us at AC 60 Hz: | 184 to 276 V |
| Rated residual current: | 0.03 to 5 A |
