Eberle 040010740300 Voltage measuring relay MRUL 24-240VUC 2W 3 measuring ranges

In stock

SKU: 313309

Price on request

€123.44

€0

Overview

The MRU monitoring relays are used to monitor alternating or direct voltages. They automatically recognize the AC or DR signal form (50 or 60 Hz). The selector switch on the front is used to choose between overvoltage and undervoltage with or without a memory function. Approvals: UL and CSA.

Property	Value
Type of voltage for actuation:	AC/DC
Max. permissible response delay time:	3 s
Number of contacts as changeover contacts:	2
Design of the electrical connection:	Screw connection
Min. adjustable response delay time:	0.1 s
Width:	35 mm
Height:	90 mm
Depth:	63.5 mm
Voltage measuring range 1:	0.2 to 60 V
Rated control supply voltage Us at AC 50 Hz:	24 to 240 V
With removable terminals:	no
1-phase undervoltage possible:	yes
3-phase undervoltage possible:	no
1-phase overvoltage possible:	yes
3-phase overvoltage possible:	no
1-phase window possible:	no
3-phase window possible:	no
Contains DC undervoltage function:	yes
Contains DC overvoltage function:	yes
Contains DC voltage window function:	no
Type of voltage of the measuring range:	AC/DC
Rated control supply voltage Us at AC 60 Hz:	24 to 240 V
Rated control supply voltage Us at DC:	24 to 240 V
