Eberle 046536390000 load shedding relay LAR 465 36

In stock

SKU: 313346

Price on request

€19.44

€0

Overview

To reduce the required cable cross-section for large consumers by mutual locking of consumers. The relay can be sealed. For mounting on a mounting rail

Property	Value
Rated voltage:	400 V
Rated current:	6.7 to 39 A
Response current:	5.7 A
Max. drop-out delay:	20 ms
Max. Continuous current:	43 A
Rated current (control contacts):	1 A
Max. switching voltage (control contacts):	400 V
Max. switching capacity (control contacts):	250 VA
Electrical service life (control contacts):	100,000 switching cycles
Mechanical service life (control contacts):	1000,000 switching cycles
Max. Electrical switching frequency:	1800 c/h
Voltage type:	AC
Mounting type:	DIN rail
Width in pitch units:	1
Installation depth:	60 mm
Protection class (IP):	IP40
Number of contacts as break contacts:	1
