ELSO 174140 40 - 1000W/VA phase control dimmer

In stock
SKU: 432981
€135.48
Into a basketIn the basketGo

Overview

Dimmer insert 40 - 1000 W/VA, flat construction, push-off switch, for incandescent and halogen lamps, 230 V 50 Hz, for low-voltage halogen lamps with conventional transformers 60 - 1000 VA (no toroidal core), for low-voltage halogen lamps with transformers ELSO UNIVERSAL 60 - 1000 VA for motor load 60 - 600 VA neutral conductor required

Property Value
Dimming leading edge: yes
Dimming trailing edge: no
Mounting type: Flush-mounted
Color: gray
Suitable for protection class (IP): IP20
Operating method: Rotary/push button
Halogen-free: yes
Composition: Basic element
Load type: inductive load
Series dimmer: no
Extension input: no
Light value memory: no
Can be used with button: no
Can be used with motion detector: no
Can be used with presence detector: no
Can be used with timer: no
Can be used with radio button: no
Can be used with IR button: no
Mounting type: Mounting with screw
Material: other
Material quality: other
Surface: untreated
Frequency: 50 Hz
Device width: 71 mm
Device height: 71 mm
Device depth: 32 mm
Nominal power: 1000 VA
Nominal voltage: 230 V
Transparent: no
App control via Bluetooth: no
Connection type: screw terminal
Wire cross-section: 1.5 mm
Min. depth of the device box: 46 mm

Characteristics

Core cross-section1.5 mm
ManufacturerELSO
HAN174140
GTIN4013984140002
Connection typeScrew terminal
Operating modeRotary/push button
Mounting typeFastening with screw
Dimming trailing edgeNo
Dimming phase controlYes
ColorGray
Frequency50Hz
Device width71 mm
Device height71 mm
Device depth32 mm
Halogen freeYes
Min. depth of the device box46 mm
Mounting typeFlush-mounted
Extension inputNo
Nominal voltage230V
SurfaceUntreated
TransparentNo
MaterialOther
Material qualityOther
CompilationBasic element
