Kaiser EX1310.25.2.100 AGRO cable gland M25, EX1310.25.2.100

In stock

SKU: 497387

Price on request

€17.38

€0

Overview

Thread length: Short, clamping technology: compression technology, technical features: For several cables, operating temperature: -60°C / +100°C, Ex: Increased safety

Property	Value
Wrench size:	30 mm
Thread pitch:	1.5 mm
Nominal thread size metric/PG:	25
Suitable for cable diameters:	8.0 to 10.0 mm
Protection class (IP):	IP68
Operating temperature:	-40 to 100 °C
Halogen-free:	yes
Thread length:	7 mm
Thread type:	metric
Design:	straight
Material:	metal
With strain relief:	yes
Surface:	nickel-plated
Type of seal:	Sealing ring
Impact resistant:	yes
Bending protection:	no
Material quality:	Brass
Fiberglass reinforced:	no
With lock nut:	no
Multiple sealing insert:	yes
Flat cable gland:	no
Dividable screw connection:	no
Explosion-tested version:	yes
For Ex-zone gas:	1, 2
For Ex-zone dust:	21, 22
