ESCHA 8045920 AL-WWAK4P2-2-AL-WAS4/S370 connecting cable

In stock

SKU: 621441

Price on request

€28.85

€0

Overview

Supply cable for CAN (DeviceNetT, CANopen), PUR cable sheath, 4-pin, supply cable: 4 x 1.5 mm2, sheath material: PUR, color: gray, sheath diameter: 7.5 mm, suitable for drag chains, oil-resistant and flame-retardant, halogen-free, cable length: 100 meters, open end, open end

Property	Value
Rated current In:	4 A
Color of the cable sheath:	black
With LED display:	yes
Material of the cable sheath:	Polyurethane (PUR)
Material of the contact base:	CuSn
Number of poles:	4
Arrangement of the cable feed, field side:	angled
Type of plug contact, housing side:	Male (plug)
Arrangement of the cable feed, housing side:	straight
Cable length:	2 m
Halogen-free:	yes
Shielded:	no
Cable design:	multi-core
Radiation-crosslinked:	no
Permissible cable external temperature after installation without vibration:	+90 °C
Permissible cable external temperature during installation/handling:	-30 °C
