Finder 7P.09.1.255.0100 SPD surge arrester type 1 spark gap

In stock
SKU: 274547
€189.47
Into a basketIn the basketGo

Overview

Surge arrester type 1, compact device, total current spark gap can be used between N - PE, must be supplemented by 1 or 3 pieces of type 7P.01.8.260.1025 in 1- and 3-phase networks, width 36 mm.

Property Value
Protection level: 1.5 kV
Nominal discharge current (8/20): 100 kA
Highest continuous voltage AC: 255 V
Mounting type: DIN rail TH35
Size: 2 TE
With remote signaling contact: no
Test class type 2: no
Max. conductor cross-section flexible (fine-stranded): 1.5 mm²
Max. Conductor cross-section rigid (single/multi-wire): 1.5 mm²
Protection level N-PE: 1.5 kV
Integrated backup fuse: no
Protection class (IP): IP20

Characteristics

Max. conductor cross-section rigid (single/multi-wire)1.5 mm²
Max. conductor cross-section flexible (fine-stranded)1.5 mm²
Protection level1.5 kV
With remote signaling contactNo
Test class type 2No
Protection level N-PE1.5 kV
Integrated backup fuseNo
ManufacturerFinder
HAN7P.09.1.255.0100
GTIN8012823354286
Size2 HP
Highest continuous voltage AC255V
Mounting typeDIN rail TH35
Nominal discharge current (8/20)100kA
IP protection)IP20
