Finder 7P.12.8.275.1012 SPD surge arrester type 1 1-phase

In stock

SKU: 274548

Price on request

€181.25

€0

Overview

Surge arrester type 1+ 2, plug-in modules, varistor between L - N and spark gap between N - PE, for 1-phase TN-S and TT networks, width 35.8 mm.

Property	Value
Highest continuous voltage AC:	275 V
Lightning impulse current (10/350 µs):	12.5 kA
Test class:	Type 1 and 2
Number of poles:	2
Nominal voltage AC:	230 V
Blow-out:	no
Size:	2 TE
Remote signaling:	yes
Signaling on the device:	optical
Network type TN-CS:	no
Network type DC:	no
Network type TN:	no
Highest continuous voltage DC:	350 V
Energetically coordinated protective effect on the end device:	yes
Mounting type:	DIN rail TH35
Protection level N-PE:	1.5 kV
Network type TT:	yes
Integrated back-up fuse:	no
Max. conductor cross-section rigid (single/multi-wire):	35 mm²
Max. Conductor cross-section flexible (fine-stranded):	25 mm²
Network type other:	no
Protection level LN:	1.2 kV
Network type TN-C:	no
Network type IT:	no
Network type TN-S:	yes
Protection class (IP):	IP20

Characteristics

Max. conductor cross-section rigid (single/multi-wire)35 mm²

Max. conductor cross-section flexible (fine-stranded)25 mm²

Lightning surge current (10/350 µs)12.5 kA

Highest continuous voltage DC350 V

Network form TTYes

Network type TN-SYes

Network form TNNo

Network type TN-CNo

Network type TN-C-SNo

Protection level L-N1.2 kV

Network type DCNo

Protection level N-PE1.5 kV

Integrated backup fuseNo

Network type ITNo

Manufacturer

HAN7P.12.8.275.1012

GTIN8012823354163

Size2 HP

Highest continuous voltage AC275V

Mounting typeDIN rail TH35

Nominal voltage AC230V

Number of poles2

IP protection)IP20

Signaling on the deviceOptical
