Catalog

Flexa 10237232029 ROHRflex PA6-D AD34,5 black solid plastic corrugated hose

In stock
SKU: 914334
€11.33
Into a basketIn the basketGo

Overview

All-plastic corrugated hose ROHRflex PA 6-D, V0 (UL 94), IP 68/IP 69K for heavy-duty applications, corrugated inside and outside, thick-walled, narrow profile Material: plastic (PA), color: black Temperature range: -40°C...+120°C ^ ... 150°C Approvals: UL 1696 - CSA 22.2 UR-File-no E86359 / EN 45545-2 (HL3) / NFPA 130 - ASTM E 162-E 662 SMP 800-C / UNI CEI 11170 / Lloyds Register of Shipping / Gost Properties: high transverse crush resistance / air and liquid tight / oil resistant up to +80°C / largely acid and solvent resistant / silicone, cadmium and halogen free / flame retardant / self-extinguishing / UV-resistant Application area: Mechanical engineering / plant engineering / vehicle construction / rail vehicles / shipbuilding / automation / electrical systems

Property Value
Lengthwise slotted: no
Nominal size in inches: 1 inch
Lockable (two-part): no
Approval according to DIN EN 61386-23: yes
Approval according to NF F 16-101: no
Nominal diameter: 34.5 mm
Inner diameter: 27.1 mm
Outer diameter: 34.3 mm
Compressive strength: 320 N
Operating temperature: -40 to +120 °C
Fire protection according to UL94: V0
Bending radius, static: 70 mm
UV-resistant: yes
Oil resistant: yes
Color: black
Coating material: without coating
Flame-spreading: no
Halogen-free: yes
Approval according to UR: yes
Approval according to VdTÜV/GGVSEB: no
Approval according to CSA: yes
Approval according to LUL/British Standard: no
Lloyds Register TA approval: yes
UTAC approval: no
DIN 5510 approval: yes
Protection class (IP): IP68
Bending behavior: flexible
Bending radius, dynamic: 120 mm
With pull wire: no
Highly slippery inner layer: no

Characteristics

Inner diameter27.1 mm
Bending radius, static70 mm
Bending behaviorFlexibel
Flame propagatingNo
HABROHRflex PA6-D AD34,5 black
Minimal order25 meters
ManufacturerFlexa
HAN10237232029
GTIN4025113194404
Outer diameter34.3 mm
Operating temperature-40 to +120 °C
ColorBlack
Halogen freeYes
Nominal diameter34.5 mm
Nominal size in inchesInch
IP protection)IP68
UV-resistantYes
