Flexa 14231101015 AIRflex-KUW-EDU AD21 15x21mm plastic protection hose

In stock

SKU: 913544

Price on request

€477.27

€0

Overview

Plastic protection hose AIRflex-KUW-EDU, 10 meter pack, IP 68 spiral-wound plastic hose, plastic-coated spring steel wire helix, soft PVC jacket, galvanized steel wire braiding Material: PVC / PVC-coated spring steel wire, / galvanized steel wire Temperature range: -25°C ...+ 90°C ^ +100°C Properties: very flexible / air and liquid-tight / tensile and torsion-resistant / largely oil and acid-resistant / silicone and cadmium-free / increased internal pressure resistance / protection against hot chips / shielding Area of application: mechanical engineering / plant engineering / vehicle construction / shipbuilding / automation / electrical systems

Property	Value
Nominal diameter:	21.0 mm
Surface:	galvanized
Sheathing material 1st layer:	Polyvinyl chloride (PVC)
Sheathing material 2nd layer (outer):	Steel wire, galvanized
Approval according to DIN EN 61386-23:	no
Nominal size in inches:	1/2 inch
Inner diameter:	15.0 mm
Outer diameter:	21.0 mm
Seal:	without seal
Operating temperature:	-25 to +90 °C
Bending radius, static:	24 mm
Weight:	0.280 kg/m
Color:	metallic
Electrical properties:	with insulating properties
Flame propagating:	no
Use in Ex areas:	no
Approval according to BWB:	no
Approval according to VDE-EMV/emc:	no
Approval according to FI:	no
With approval according to UL:	no
Approval according to CSA:	no
Material:	Steel
Protection class (IP):	IP68
Bending behavior:	flexible
