Flexa 14231101037 AIRflex-KUW-EDU AD45 37x45mm plastic protection hose

In stock

SKU: 913547

Price on request

€629.50

€0

Overview

Plastic protection hose AIRflex-KUW-EDU, 10 meter pack, IP 68 spiral-wound plastic hose, plastic-coated spring steel wire helix, soft PVC jacket, galvanized steel wire braiding Material: PVC / PVC-coated spring steel wire, / galvanized steel wire Temperature range: -25°C ...+ 90°C ^ +100°C Properties: very flexible / air and liquid-tight / tensile and torsion-resistant / largely oil and acid-resistant / silicone and cadmium-free / increased internal pressure resistance / protection against hot chips / shielding Area of application: mechanical engineering / plant engineering / vehicle construction / shipbuilding / automation / electrical systems

Property	Value
Nominal diameter:	45.0 mm
Surface:	galvanized
Sheathing material 1st layer:	polyvinyl chloride (PVC)
Sheathing material 2nd layer (outer):	steel wire, galvanized
Approval according to DIN EN 61386-23:	no
Nominal size in inches:	1 1/4 inch
Inner diameter:	37.0 mm
Outer diameter:	45.0 mm
Seal:	without seal
Operating temperature:	-25 to +90 °C
Bending radius, static:	48 mm
Weight:	0.820 kg/m
Color:	metallic
Electrical properties:	with insulating properties
Flame propagating:	no
Use in Ex area:	no
Approval according to BWB:	no
Approval according to VDE-EMV/emc:	no
Approval according to FI:	no
With approval according to UL:	no
Approval according to CSA:	no
Material:	steel
Protection class (IP):	IP68
Bending behavior:	flexible
