Flexa 15020130013 US-K PG13 hose fitting

In stock

SKU: 911916

Price on request

€10.90

€0

Overview

Plastic screw connection straight USK-P, IP 54 suitable for plastic protective hoses AIRflex-KUW-PVC-AS / AIRflex-KUW-PU-AS / AIRflex-K / AIRflex-GRS incl. inner sleeve and sealing ring, PG external thread Material: plastic (PP), color: gray Temperature range: -10°C ... +110°C Approvals: UL 1696-UR file E86359 / CSA 22.2, file 227.3-05 Properties: high protection against dust and liquids / force-locking connection between hose and screw connection / vibration- and tensile-resistant

Property	Value
Nominal size in inches:	other
Perm. in combination with protective hose DIN EN 61386-23:	no
With integrated holder:	no
Thread connection size:	PG13.5
Material of the screw connection:	Polypropylene (PP)
Nominal diameter:	19.0 mm
Design:	straight
Rotatable thread:	no
Design:	External thread
Connection type:	Thread
Thread length:	10.0 mm
One-piece:	no
Seal material:	Thermoplastic elastomers (TPE)
Smallest inner diameter of the hose:	15.0 mm
Largest outer diameter of the hose:	19.0 mm
Total height:	32.0 mm
Color:	gray
Approved in combination with protective hose UR:	yes
Total length:	41.0 mm
Protection class (IP):	IP54
