Flexa 15020330050 USK-M50 hose fitting

In stock

SKU: 911942

Price on request

€41.12

€0

Overview

Plastic screw connection straight USK-M, IP 54 suitable for plastic protective hoses AIRflex-KUW-PVC-AS / AIRflex-KUW-PU-AS / AIRflex-K / AIRflex-GRS including inner sleeve and sealing ring, metric external thread Material: plastic (PP), color: gray Temperature range: -10°C ... +110°C Approvals: UL 1696-UR file E86359 / CSA 22.2, file 227.3-05 Properties: high dust and liquid protection / force-locking connection of hose and screw connection / vibration and tensile strength

Property	Value
Nominal size in inches:	1 1/2 inch
Perm. in combination with protective hose DIN EN 61386-23:	no
With integrated holder:	no
Thread connection size:	M50 x 1.5
Material of the screw connection:	Polypropylene (PP)
Nominal diameter:	56.0 mm
Design:	straight
Rotatable thread:	no
Design:	External thread
Connection type:	Thread
Thread length:	16.0 mm
One-piece:	no
Seal material:	Thermoplastic elastomers (TPE)
Smallest inner diameter of the hose:	48.0 mm
Largest outer diameter of the hose:	56.0 mm
Total height:	77.0 mm
Color:	gray
Approved in combination with protective hose UR:	yes
Total length:	58.0 mm
Protection class (IP):	IP54
