Hager SPA180N T1+T2 1P N-PE Iimp 100kA combined surge arrester

Hager SPA180N T1+T2 1P N-PE Iimp 100kA combined surge arrester

In stock

SKU: 770357

Price on request

€272.73

€0

Overview

Combined arrester T1+T2 1P N-PE Iimp 100kA Uc 1.5KV remote signaling contact backup fuse. Combined arrester type 1 and type 2 in accordance with DIN EN 61643-11 (VDE 0675-6-11) with integrated arrester backup fuse. Base element can be mounted variably and plug-on protection module can be replaced. For N-PE plugs and with suitable phase rail and arrester for L-PEN plugs, connection to 3+1 circuit. Combined arrester with remote signaling contact for monitoring device (potential-free changeover contact), function/defect indication by marking in the viewing window, encapsulated, non-blow-out design.

Property	Value
Lightning impulse current (10/350 µs):	100 kA
Nominal discharge current (8/20):	100 kA
Maximum continuous voltage AC:	350 V
Nominal voltage AC:	240 V
Protection level:	1.5 kV
Follow current extinguishing capacity:	50 kA
Mounting type:	DIN rail TH15
Size:	2 TE
With remote signaling contact:	yes
Blow-out:	no
Signaling on the device:	optical
Test class type 1:	yes
Protection level N-PE:	1.5 kV
Suitable for outdoor use:	no
Network type TT:	yes
Network type TN-CS:	yes
Integrated back-up fuse:	yes
Network type TN-S:	yes
Max. conductor cross-section rigid (single/multi-wire):	35 mm²
Max. Conductor cross-section flexible (fine-stranded):	35 mm²
Network type other:	no
Network type TN:	yes
Network type TN-C:	yes
Number of conductors (without earth):	1
Protection class (IP):	IP20
