Hager SPN513 surge arrester 3-pole 40kA Type 2 IT A

In stock
SKU: 307593
€193.78
Into a basketIn the basketGo

Overview

Surge arrester 3 pole 40kA type 2 IT system with defect indicator. 3-pole, modular surge arrester for 400/690V, IT systems, arrester type 2 according to EN 61643-11, high-performance varistor technology, base part with plugged-in protection modules, simple, tool-free protection module change thanks to module locking system with module release button, highest continuous voltage: 440 V AC, protection level: <= 2 kV, nominal discharge current: 20 kA, energy coordination according to DIN EN 62305-4 (VDE 0185-305-4) with type 1, series-mounted device according to DIN 43880, 3TE.

Property Value
Protection level: 2 kV
Nominal discharge current (8/20): 20 kA
Maximum continuous voltage AC: 440 V
Nominal voltage AC: 400 V
Protection level LN: 1.5 kV
Mounting type: DIN rail TH35
Signaling on the device: optical
With remote signaling contact: no
Test class type 2: yes
Protection level N-PE: 1.5 kV
Protection class (IP): IP20
Network type other: yes
Max. discharge current (8/20): 40 kA

Characteristics

Protection level2 kV
With remote signaling contactNo
Max. discharge current (8/20)40 kA
Test class type 2Yes
Protection level L-N1.5 kV
Protection level N-PE1.5 kV
ManufacturerHAGER
HANSPN513
GTIN3250615660794
Highest continuous voltage AC440V
Mounting typeDIN rail TH35
Nominal discharge current (8/20)20kA
Nominal voltage AC400V
IP protection)IP20
Signaling on the deviceOptical
