Harting 09140123101 socket module

In stock

SKU: 624903

Price on request

€2.62

€0

Overview

Han DD module, single module, crimp connection, socket, contacts: 12, conductor cross-section: 0.14...2.5 mm², rated current: 10 A, polycarbonate (PC), RAL 7032 (pebble grey)

Property	Value
Number of poles:	12
Rated current In:	10 A
Rated impulse voltage:	4 kV
With protective conductor:	no
Connectable conductor cross-section, stranded:	0.14 to 2.5 mm²
Material of the connector insert:	Thermoplastic
Rated voltage:	250 V
Contact design:	Socket
Pollution level:	3
Material of the contact:	other
Connectable conductor cross-section, fine-stranded without wire end ferrule:	0.14 to 2.5 mm²
Contact insert without contacts:	yes
Material of the contact coating:	other
Design of the electrical connection:	crimp connection
With wire protection:	no
Flammability class of the insulating material according to UL 94:	V0
Material of the contact insert:	Thermoplastic
Number of power contacts:	12
Operating temperature:	-40 to 125 °C
Min. number of mating cycles:	500
