Harting 09160243001 HAN 24DD-STI-C pin contact

In stock

SKU: 624923

Price on request

€19.83

€0

Overview

Inserts, crimp connection, pin, polycarbonate, RAL 7032 (pebble grey), rated current: 10A, size: 6 B, contacts: 24, conductor cross-section: 0.14...2.5mm

Property	Value
Number of poles:	24
Rated current In:	10 A
Rated impulse voltage:	4 kV
With protective conductor:	yes
Connectable conductor cross-section, stranded:	2.5 to 0.14 mm²
Material of the connector insert:	Thermoplastic
Rated voltage:	600 V
Overvoltage category:	III
Ambient temperature:	125 to -40 °C
Contact design:	Pin
Diameter of the plug contact:	1.6 mm
Pollution level:	3
Material of the Contacts:	other copper alloys
Connectable conductor cross-section, single-wire:	0.14 to 2.5 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.14 to 2.5 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule:	0.14 to 2.5 mm²
Contact insert without contacts:	yes
Material of the contact coating:	other
Design of the electrical Connection:	Crimp connection
With wire protection:	no
Flammability class of the insulating material according to UL 94:	V0
Material of the contact insert:	other
Number of power contacts:	24
Operating temperature:	-40 to 125 °C
Min. number of mating cycles:	500
