Harting 09340032601 HAN 3 HVE-STI-S pin contact

In stock

SKU: 625026

Price on request

€11.36

€0

Overview

Inserts, screw connection, pin, polycarbonate, RAL 7032 (pebble grey), rated current: 16A, size: 10 B, contacts: 3, + 2 additional switching contacts, conductor cross-section: 0.75...2.5mm, copper alloy, silver-plated

Property	Value
Number of poles:	3
Rated current In:	16 A
Rated impulse voltage:	8 kV
With protective conductor:	yes
Connectable conductor cross-section stranded:	2.5 to 0.75 mm²
Material of the connector insert:	Thermoplastic
Rated voltage:	600 V
Overvoltage category:	III
Ambient temperature:	125 to -40 °C
Contact design:	Pin
Diameter of the plug contact:	2.5 mm
Pollution level:	3
Material of the contact:	other copper alloys
Connectable conductor cross-section, single-wire:	0.75 to 2.5 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.75 to 2.5 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule:	0.75 to 2.5 mm²
Contact insert without contacts:	no
Material of the contact coating:	silver
Design of the electrical connection:	Screw connection
With wire protection:	no
Flammability class of the insulating material according to UL 94:	V0
Material of the contact insert:	Thermoplastic
Number of power contacts:	5
Operating temperature:	-40 to 125 °C
Min. Number of mating cycles:	500
