Harting 09700062616 socket insert

In stock
SKU: 625090
€4.82
Into a basketIn the basketGo

Overview

Inserts, screw connection, pin, polyamide (PA), black, rated current: 10 A, size: 3 A, contacts: 6, conductor cross-section: 1.5 mm², copper alloy, silver-plated

Property Value
Number of poles: 6
Rated current In: 10 A
Rated impulse voltage: 0.8 kV
With protective conductor: no
Connectable conductor cross-section, stranded: 1.5 mm²
Material of the connector insert: Thermoplastic
Rated voltage: 25 V
Contact design: Pin
Pollution level: 3
Material of the contact: other copper alloys
Connectable conductor cross-section, fine-stranded without wire end ferrule: 1.5 mm²
Contact insert without contacts: no
Material of the Contact coating: Silver
Design of the electrical connection: Screw connection
With wire protection: no
Flammability class of the insulating material according to UL 94: HB
Material of the contact insert: Thermoplastic
Number of power contacts: 6
Operating temperature: -40 to 100 °C
Min. Number of mating cycles: 500

Characteristics

Rated surge voltage0.8 kV
HAB9700062616
ManufacturerHarting
HAN09700062616
GTIN5713140102866
Connectable conductor cross-section stranded1.5 mm²
Design of the electrical connectionScrew connection
Rated voltage25V
Rated current In10A
Operating temperatur-40 to 100 °C
Flammability class of the insulating material according to UL 94HB
Number of poles6
Degree of contamination3
