Kopp 827803002 PM360-AP-12-M-1-ws presence detector

Kopp 827803002 PM360-AP-12-M-1-ws presence detector

In stock

SKU: 710556

Price on request

€90.37

€0

Overview

Presence detector PM360-AP-12-M-1-ws, detection angle 360°, installation: surface-mounted, detection range up to 12 m, protection class IP20, infrared detection, master, 1 channel for switching light, white, 230 VAC, 50 Hz. Incandescent lamps: 2,000 W High-voltage halogen lamps: 1,000 VA Fluorescent lamps: 900 VA (100µF) Energy-saving lamp: 600 VA LED: 400 W/VA, run-on time: 30 sec. - 30 min., pulse output 1 sec., response brightness continuously variable 10 - 2000 lux., remote controllable (IR remote control optional)

Property	Value
Depth:	82,000 mm
Design:	Presence detector
Voltage type:	AC
Protection class (IP):	IP20
Max. switching capacity:	2000 W
Min. duty-on time:	30 s
Max. duty-on time:	30 min
Max. inrush current:	10 A
Max. Range to one side:	6,000 m
Max. presence area:	12,500 m²
Max. Frontal range:	6,000 m
Horizontal detection angle:	360 °
Color:	white
RAL number (similar):	9010
Material:	Plastic
Installation height:	2,500 m
Installation type:	Surface-mounted
Response brightness:	10 to 2000 lx
Response brightness adjustable:	yes
Creep-under protection:	no
Temperature:	-20 to 50 °C
Response sensitivity adjustable:	yes
Sensor type:	passive infrared
Surface finish:	matt
Surface protection:	painted
Material quality:	thermoplastic
Diameter of detection field on floor:	12.00 m
Switch-off delay:	300 s
Switch-on delay:	10 s
Frequency:	50 Hz
Sensor swivel range, vertical:	0 °
Sensor swivel range, horizontal:	0 °
Halogen-free:	yes
Constant light control:	no
HVAC control:	no
Forced shutdown:	yes
Animal corridor:	no
Networkable:	yes
Automatic stair light:	no
Bypass switch:	no
Suitable for wireless transmission:	no
Remote controllable:	yes
With signal unit:	no
Alarm function:	no
Teach function for response brightness:	yes
Dimming function with dimming insert:	no
Transparent:	no
With remote control:	no
Suitable for C load:	yes
With DALI interface:	no
Extension input:	yes
Forced switching on:	yes
Suitable for ceiling mounting:	yes
Connection type:	plug-in terminal
Antibacterial treatment:	no
Diameter:	112 mm
Installation depth:	.000 mm
Min. depth of device box:	.000 mm
Max. LED switching capacity:	400 W
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	no

Characteristics

Bridging switchNo

With signal unitNo

Response brightness10 to 2000 lx

Forced shutdownYes

Max. inrush current10 A

Forced switching onYes

Max. presence range12.500 m²

HABPM360-AP-12-M-1-ws

Manufacturer

HAN827803002

GTIN4008224642941

Dimming function with dimming insertNo

Alarm functionNo

Connection typePlug-in terminal

Response sensitivity adjustableYes

Response brightness adjustableYes

Antibacterial treatmentNo

VersionPresence detector

Surface finishFrosted

Diameter112 mm

Installation depth.000 mm

Detection angle horizontal360°

Color

Remote controllableYes

Frequency50Hz

Suitable for C-loadYes

Suitable for ceiling mountingYes

Suitable for wireless transmissionNo

HVAC controlNo

Halogen freeYes

IFTTT support availableNo

Compatible with Amazon AlexaNo

Compatible with Apple HomeKitNo

Compatible with Google AssistantNo

Constant light controlNo

Max. duty cycle30 min

Max. range frontal6,000m

Max. range to one side6,000m

Max. switching capacity2000W

Min. duty cycle30s

Min. depth of the device box.000 mm

With DALI interfaceNo

With remoteNo

Mounting typeSurface-mounted

Extension inputYes

Surface protectionPainted

RAL number (similar)9010

IP protection)IP20

Sensor typePassive infrared

Voltage typeAC

Teach function for response brightnessYes

Temperature-20 to 50 °C

Depth82,000 mm

Animal corridorNo

TransparentNo

NetworkableYes

MaterialPlastic

Material qualityThermoplastic
