Jacob 50.650 PA/R M50 polyamide silver grey RAL7001 PERFECT cable gland

In stock

SKU: 908263

Price on request

€5.54

€0

Overview

Reducing sealing ring for small cables, integrated strain relief, large sealing and clamping area, easy to install, RAL7001, connection thread standard length, cable gland metric plastic

Property	Value
Wrench size:	55 mm
Thread pitch:	1.5 mm
Nominal thread size metric/PG:	50
Suitable for cable diameters:	21 to 35 mm
Protection class (IP):	IP68
Operating temperature:	-20 to 100 °C
Halogen-free:	no
Thread length:	12 mm
Thread type:	metric
Design:	straight
Material:	plastic
With strain relief:	yes
Surface:	untreated
Type of seal:	Sealing ring
Impact-resistant:	yes
Bending protection:	no
RAL number:	7001
Material quality:	Polyamide (PA)
Glass fiber reinforced:	no
With lock nut:	no
Multiple sealing inserts:	no
Flat cable gland:	no
Dividable gland:	no
Explosion-tested version:	no
For Ex-zone gas:	without
For Ex-zone dust:	without
Snaps into opening:	no
For armored cables:	no
EMC version:	no
Shielded:	no

Characteristics

Impact resistantYes

Explosion-tested versionNo

Nominal thread size metric/PG50

Fiberglass reinforcedNo

ShieldedNo

Suitable for cable diameter21 to 35mm

Wrench size55 mm

HABM50 polyamide silver grey RAL7001

Minimal orderPcs

Manufacturer

HAN50.650 PA/R

GTIN4024092066665

VersionStraight

EMC versionNo

Operating temperature-20 to 100 °C

Thread typeMetric

Thread length12 mm

Thread1.5 mm

Halogen freeNo

With strain reliefYes

SurfaceUntreated

RAL number7001

IP protection)IP68

MaterialPlastic

Material qualityPolyamide (PA)

Jacob 50.650 PA/R M50 polyamide silver grey RAL7001 PERFECT cable gland
