Legrand 384393 screw connection PSP M32 D=18-25 black, (light grey)

In stock

SKU: 244555

Price on request

€2.21

€0

Overview

Screw connection M32x1.5, ø cable: min.: 18 mm, max.: 25 mm, torque: nut: 14 Nm, body: 7 Nm, impact load: 5, color: RAL 9011

Property	Value
Thread pitch:	1.5 mm
Nominal thread size metric/PG:	25
Suitable for cable diameters:	13 to 18 mm
Protection class (IP):	IP68
Operating temperature:	-20 to 80 °C
Halogen-free:	yes
Thread length:	10 mm
Thread type:	metric
Design:	straight
Material:	plastic
With strain relief:	no
Type of seal:	sealing ring
Impact-resistant:	yes
Bending protection:	no
RAL number:	7035
Material quality:	Polyamide (PA)
Fiberglass reinforced:	no
With lock nut:	no
Multiple sealing inserts:	no
Flat cable screw connection:	no
Dividable screw connection:	yes
Explosion-tested version:	no
For Ex-zone gas:	without
For Ex-zone dust:	without
