Legrand 664715 button Niloe illuminated incl. LED ultra-white white, (cream white (electric white))

Legrand 664715 button Niloe illuminated incl. LED ultra-white white, (cream white (electric white))

In stock

SKU: 242370

Price on request

€12.56

€0

Overview

Inserts are supplied including a rocker/cover and protective cover. Fastening using screws or spreading claws - inserts for screw fastening can be retrofitted with spreading claws Order No. 6650 99. Connection using a plug (SL) or screw terminals (SK). Supplied with LED unit Order No. 6650 90 and pictogram -bell-, -lock- and -light-.

Property	Value
Color:	white
Design:	Single button
Suitable for protection class (IP):	IP31
Operating mode:	Rocker
Mounting type:	Flush-mounted
Number of rocker switches:	1
Halogen-free:	yes
Text field/labeling area:	yes
Composition:	Base element with central cover plate
Feedback contact:	no
With lighting:	yes
Mounting type:	Screw fastening
Material:	Plastic
Material quality:	Thermoplastic
Surface:	untreated
Surface finish:	glossy
RAL number (similar):	9003
Nominal voltage:	250 V
Number of modules (with modular design):	2
Print:	'Bell' symbol
Rated current:	6 A
Device width:	75.8 mm
Device height:	75.8 mm
Device depth:	34 mm
Number of poles:	2
Transparent:	no
Antibacterial treatment:	no
With signal lamp:	yes
Min. depth of device box:	40 mm
