Insert Module TypeLight switch covers
ColorWhite
Bridging switchYes
With signal unitYes
Response brightness5 to 1275 lx
Forced shutdownNo
Max. inrush current8.5 A
HAN078452
GTIN3245060784522
Dimming function with dimming insertNo
Alarm functionYes
Connection typeScrew terminal
Response sensitivity adjustableYes
Response brightness adjustableYes
Antibacterial treatmentNo
VersionPresence detector
Surface finishGlittering
Installation depth35 mm
Detection field diameter on floor6m
Detection angle horizontal0 to 180 °
Remote controllableYes
Frequency50 to 60 Hz
Suitable for wireless transmissionNo
HVAC controlNo
Constant light controlYes
Max. duty cycle59 min
Max. range frontal8m
Max. range to one side3m
Max. switching capacity2000W
Min. duty cycle5s
With DALI interfaceNo
With remoteNo
Mounting typeFlush-mounted
Extension inputYes
Nominal voltage230V
SurfaceUntreated
Optimal mounting height1.2m
RAL number (similar)9003
IP protection)IP41
Sensor typeOther
Voltage typeAC
Teach function for response brightnessNo
Temperature-5 to 45 °C
Animal corridorNo
TransparentNo
Staircase monitoringNo
Creep protection/rear field monitoringYes
NetworkableNo
MaterialPlastic
Material qualityThermoplastic
