Insert Module TypeLight switch covers
HAN060483
GTIN3245060604837
Covering the luminaire with thermal insulation material possibleNo
Execution of the gridWithout
Outer diameter228 mm
Rated luminous flux according to IEC 62722-2-1985lm
Rated ambient temperature according to IEC62722-2-1-10 to 40 °C
Operating deviceNot required
Suitable for computer workstations according to EN 12464-1No
Width228 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Installation length228 mm
Color temperature2700K
Color rendering index CRI90-100
VersionE27
Suitable for surface mountingYes
Suitable for ceiling mountingYes
Suitable for flush mountingNo
Suitable for lamp power100W
Suitable for number of lamps1
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorGray
Height/Depth127 mm
Luminaire with limited surface temperature D-markNo
LampsLight bulb
Light emissionDirect
Light colorWhite
Light distributorDiffuser lens/optics/panel
Light distributionAsymmetrical
Length228 mm
Max. system performance100W
With operating deviceNo
With motion detectorNo
With light sourceNo
With light sensorNo
With air slotsNo
Nominal voltage110 to 230 V
Without dimming functionYes
Impact resistanceIK04
IP protection)IP55
Protection classI
Voltage typeAC
Cover materialGlass structured
Housing materialAluminum
