Housing can be easily removed for cleaning without tools. Pleasantly quiet. Dirt-free and quick replacement of existing EN devices, as it is 100% compatible with the previous EN and ET devices. For existing electrical external flaps with a plug connection: Disconnect the plug and reconnect the individual wires according to the EN/ENR circuit diagrams on the Internet. Fan maintenance-free. Motor: Thermal overload protection as standard. Robust motor. Suitable for continuous operation. Electrical connection: Electrical connection can be surface-mounted or flush-mounted. Safety instructions: The fan may only be operated if the impeller is protected against contact in accordance with DIN EN ISO 13857. Article: EN 20, delivery volume: 420 m3/h, speed: 1350 1/min, impeller type: axial, air direction: ventilation, speed controllable: yes, reversibility: no, voltage type: alternating current, rated voltage: 230 V, mains frequency: 50 Hz, rated power: 30 W, IMax: 0.21 A, protection class: IP 44, mains cable: 3 / 1.5 mm2, installation location: wall / ceiling, installation type: surface-mounted, installation position: any, material: plastic, color: traffic white, similar to RAL 9016, weight: 2.475 kg, weight with packaging: 3.035 kg, nominal width: 200 mm, width: 320 mm, height: 320 mm, Depth: 158 mm, width with packaging: 350 mm, height with packaging: 350 mm, depth with packaging: 170 mm, conveying medium temperature at IMax: 40 °C, sound pressure level: 45 dB(A)
| Property | Value |
| Design: | Ventilation |
| Speed: | 1350 1/min |
| Volume flow: | 420 m³/h |
| Nominal diameter: | 200 mm |
| Mains frequency: | 50 Hz |
| Rated voltage: | 230 V |
| Protection class (IP): | IP44 |
