Maico 0081.0316 Wall-mounted fan ENR 20

In stock
SKU: 296071
€436.10
Into a basketIn the basketGo

Overview

Housing can be easily removed for cleaning without tools. Pleasantly quiet. Dirt-free and quick replacement of existing EN devices, as it is 100% compatible with the previous EN and ET devices. For existing electrical external flaps with a plug connection: Disconnect the plug and reconnect the individual wires according to the EN/ENR circuit diagrams on the Internet. Fan maintenance-free. Motor: Thermal overload protection as standard. Robust motor. Suitable for continuous operation. Electrical connection: Electrical connection can be surface-mounted or flush-mounted. Safety instructions: The fan may only be operated if the impeller is protected against contact in accordance with DIN EN ISO 13857. Article: ENR 20, delivery volume: 460 m3/h, speed: 1380 1/min, impeller type: axial, air direction: ventilation or exhaust, speed controllable: yes, reversibility: yes, voltage type: alternating current, rated voltage: 230 V, mains frequency: 50 Hz, rated power: 42 W, INom: 0.15 A, IMax: 0.21 A, protection class: IP 44, mains cable: 5 / 1.5 mm2, installation location: wall / ceiling, installation type: surface-mounted, installation position: any, material: plastic, color: traffic white, similar to RAL 9016, weight: 2.695 kg, weight with packaging: 3.26 kg, nominal width: 200 mm, width: 320 mm, height: 320 mm, depth: 158 mm, width with packaging: 355 mm, height with packaging: 355 mm, depth with packaging: 185 mm, conveying medium temperature at IMax: 40 °C, sound pressure level: 48 dB(A)

Property Value
Design: Ventilation
Speed: 1380 1/min
Volume flow: 460 m³/h
Nominal diameter: 200 mm
Mains frequency: 50 Hz
Rated voltage: 230 V
Protection class (IP): IP44

Characteristics

ManufacturerMaico
HAN0081.0316
GTIN4012799813163
VersionVentilation
Rated voltage230V
IP protection)IP44
Maico 0081.0316 Wall-mounted fan ENR 20
Maico 0081.0316 Wall-mounted fan ENR 20
€436.10
Into a basketIn the basketGo
