Humidity control version with adjustable run-on: Barrier-free product, as it switches on/off automatically. With VDE mark. Switch-on humidity adjustable from approx. 50% relative humidity to approx. 90% relative humidity. An additional switch can be used to switch manually, the fan then runs for the set run-on time. Run-on adjustable from approx. 0.5 min to approx. 18 min. Humidity control has priority. Speed cannot be controlled. Particularly quiet thanks to the innovative piano impeller. Cover can be removed for cleaning without tools. Compatible with ECA 100 ipro and ECA predecessor models DN 100, same position of screw holes and cable entry. Protection class IP X4 for safety in the bathroom. Protection class II. Integrated springless check valve, durable and stable. Color traffic white similar to RAL 9016. Suitable for pipe DN 100. Housing made of impact-resistant plastic. Thermal overload protection. Motor: Robust motor with ball bearing, maintenance-free. Suitable for continuous operation. Installation instructions: Very easy to install, as the cover can be removed without tools. Can be mounted on the wall or ceiling. For ceiling mounting, drilling in the cover is necessary. Electrical connection: Flush-mounted electrical connection. Safety instructions: All ECA piano devices can be used in protection area 2 in accordance with DIN0100-701. For details see planning information. Article: ECA piano H, Design: Humidity control with adjustable run-on, Delivery volume: 80 m3/h, Speed: 2400 1/min, Speed controllable: no, Reversibility: no, Voltage type: Alternating current, Rated voltage: 230 V, Mains frequency: 50 Hz / 60 Hz, Nominal power: 8 W, IMax: 0.06 A, Protection class: IP X4, Mains cable: 3/5 x 1.5 mm2, Installation location: Wall / ceiling, Installation type: Surface-mounted, Installation position: Any, Material: Plastic, Color: traffic white, similar to RAL 9016, Weight: 0.5 kg, Weight with packaging: 0.63 kg, Nominal width: 100 mm, Width: 151 mm, Height: 151 mm, Depth: 104 mm, Width with packaging: 160 mm, Height with packaging: 160 mm, Depth with packaging: 130 mm, conveying medium temperature at IMax: 40 °C, run-on time: 0.5 min - 18 min - run-on time available when using an optional switch (e.g. light switch), sound pressure level: 26 dB(A) / distance 3 m, free field conditions
| Property | Value |
| Volume flow: | 80 m³/h |
| Color: | white |
| Rated voltage: | 230 V |
| Protection class (IP): | IPX4 |
| Mounting type: | Surface-mounted |
| Mains frequency: | 50 Hz |
| Nominal diameter: | 100 mm |
| Housing material: | Plastic |
| Composition: | other |
| Design: | Axial |
| Direction: | Ventilation |
