Single room ventilation: Fire protection housing to accommodate a fan ER 60, ER 100. Installation in apartment kitchens, bathrooms and toilets. With maintenance-free fire protection shut-off device to prevent fire spread K90-18017. Metal discharge nozzle DN 75/80 with metal shut-off flap and automatic release device. Metal shut-off flap also serves as a cold smoke flap. Easily removable non-return flap, making cleaning quick and easy. Can be installed inside the shaft in the wall and ceiling. Approved for wall installation with discharge direction upwards, right or left, as well as ceiling installation. Low installation depth of the flush-mounted housing and cover. With plaster protection cover. Practical snap fastening and electrical plug connection for quick installation of the fan in the housing. Plastic parts normally flammable according to class B 2. General building approval, approval no.: Z-51.1-46. Approval notices on request or on our homepage www.maico-ventilatoren.com.Article: ER - UPB, Design: Metal discharge nozzle on the side with metal shut-off flap with automatic release device, with fire protection housing, no second room connection possible, Air direction: Ventilation, Installation location: Wall / ceiling, Installation type: Flush-mounted, Material: Plastic, Color: black, Weight: 2.585 kg, Weight with packaging: 2.9 kg, Fire protection: yes, Shut-off device: integrated, Blow-out direction: side, Connection diameter: 75 mm / 80 mm, Width: 249 mm, Height: 249 mm, Depth: 120 mm, Width with packaging: 285 mm, Height with packaging: 350 mm, Depth with packaging: 140 mm, Approval number: Z-51.1-46
Property | Value |
Color: | black |
Connection diameter: | 75 mm |
With fire protection barrier: | yes |
Installation height: | 249 mm |
Installation width: | 249 mm |
Installation depth: | 120 mm |
Housing material: | Plastic |
