OBO Bettermann GK-FS53130LGR rigid form flat angle, 6113262

OBO Bettermann GK-FS53130LGR rigid form flat angle, 6113262

In stock

SKU: 509234

Price on request

€38.58

€0

Into a basketIn the basketGo

Overview

Flat angle for changing the direction of the Rapid 45-2 device installation ducts.

Property	Value
Width:	130 mm
Color:	gray
RAL number:	7035
Material:	Plastic
Material quality:	Polyvinyl chloride (PVC)
Depth:	53 mm
Design:	Lower part and upper part
Number of upper parts:	2
Top part width 1:	45 mm
Top part width 2:	45 mm
Direction:	rising/falling
Symmetrical:	yes
Angle:	90 °
Halogen-free:	no
With protective film:	yes
With channel connector:	no
Mounting holes in the base:	yes
Mounting type of upper parts:	internal
With cable retaining clip:	no
Antibacterial treatment:	no
Protection class (IP):	IP40
Impact resistance:	IK08
Operating temperature:	-15 to 60 °C

Characteristics

HABGK-FS53130LGR rigid form

Manufacturer

HAN6113262

GTIN4012196419609

Antibacterial treatmentNo

VersionBottom and top

Width130 mm

Operating temperature-15 to 60 °C

Color

Halogen freeNo

RAL number7035

Impact resistanceIK08

IP protection)IP40

Depth53 mm

MaterialPlastic

Material qualityPolyvinyl chloride (PVC)
