Mechanical installation condition for sensorNot flush
Design of the switching functionCloser
Switching frequency1000 Hz
Supply voltage10 to 30 V
HABE2S-Q21 1M OM
HAN231595
GTIN4536854841682
Type of operationMetallic target
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the switching outputTwo-wire
Design of the electrical connectionCable
Rated control supply voltage Us at DC12 to 24 V
Housing coatingOther
Width of the sensor8.9 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height of the sensor8.4 mm
Length of the sensor26 mm
Performance Level according to EN ISO 13849-1Level a
SIL according to IEC 61508Without
Switching distance2.5 mm
Voltage typeDC
Supply voltage10 to 30 V
Housing materialPlastic
