OMRON 232895 E3JM-DS70R4-G OMS photo switch

OMRON 232895 E3JM-DS70R4-G OMS photo switch

In stock

SKU: 609536

Price on request

€232.59

€0

Into a basketIn the basketGo

Overview

Photo switch, - reflection light sensor, sensing range 700mm

Property	Value
Sensing range:	0 to 700 mm
Rated control supply voltage Us at AC 50 Hz:	24 to 240 V
Rated control supply voltage Us at AC 60 Hz:	24 to 240 V
Rated control supply voltage Us at DC:	12 to 240 V
Max. Output current:	100 mA
Button function:	light/dark switching
Protection class (IP):	IP66
Length of sensor:	75 mm
Width of sensor:	25 mm
Height of sensor:	80 mm
With analog communication interface:	no
With RS-422 communication interface:	no
Max. Switching distance:	700 mm
Response time:	5 ms
Reflector included in delivery:	no
Analog output -10 V ... +10 V:	no
With Ethernet communication interface:	no
Analog output 0 mA ... 20 mA:	no
With SSD communication interface:	no
AWG number:	22
With other analog output:	no
Safety type according to IEC 61496-1:	1
With communication interface SSI:	no
With monitoring function of downstream devices:	no
Analog output 0 V ... 10 V:	no
Sensor wavelength:	950 nm
With communication interface RS-232:	no
With communication interface AS-Interface:	no
Number of semiconductor outputs with signaling function:	2
With restart lock:	no
Analog output 4 mA ... 20 mA:	no
With communication interface PROFIBUS:	no
With communication interface RS-485:	no
With communication interface DeviceNet:	no
With communication interface INTERBUS:	no
Design of the interface for safety-related communication:	other
With communication interface CANOpen:	no
Suitable for safety functions:	no
Design of the electrical connection:	screw connection
Design of the switching output:	PNP
Design of the switching function:	antivalent
Equipment protection class:	Protection class 0
Setting method:	manual setting
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Housing design:	Cuboid
Laser protection class:	without
Light type:	Infrared light
Light spot:	100 mm²
Switching frequency:	100 Hz
Type of voltage:	AC/DC
Ambient temperature:	-25 to 55 °C
Pre-failure warning:	no
Material of the optical surface:	Plastic
Material of the housing:	Plastic
Material of the cable sheath:	other
With time function:	no
Protection class (NEMA):	other

Characteristics

Design of the switching functionAntivalent

Switching frequency100 Hz

HABE3JM-DS70R4-G OMS

Manufacturer

HAN232895

GTIN4536854779466

Design of the interface for safety-related communicationOther

Design of the switching outputPNP

Design of the electrical connectionScrew connection

Rated control supply voltage Us at AC 50 Hz24 to 240 V

Rated control supply voltage Us at AC 60 Hz24 to 240 V

Rated control supply voltage Us at DC12 to 240V

Width of the sensor25 mm

Explosion protection category for gasWithout

Explosion protection category for dustWithout

Suitable for security functionsNo

Housing designCuboid

Height of the sensor80 mm

Length of the sensor75 mm

IP protection)IP66

Protection class (NEMA)Other

Voltage typeAC/DC

Ambient temperature-25 to 55 °C

Housing materialPlastic
