Diameter of the sensor18 mm
Mechanical installation condition for sensorFlush
Design of the switching functionCloser
Switching frequency600 Hz
Supply voltage24 to 240 V
HABE2F-X5Y1 2M OMS
HAN235699
GTIN4547648321372
Type of operationMetallic target
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the switching outputTwo-wire
Design of the electrical connectionCable
Rated control supply voltage Us at AC 50 Hz24 to 240 V
Rated control supply voltage Us at AC 60 Hz24 to 240 V
Housing coatingOther
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCylinder, thread
Length of the sensor47 mm
Performance Level according to EN ISO 13849-1Level a
SIL according to IEC 61508Without
Switching distance5 mm
Voltage typeAC
Supply voltage24 to 240 V
Housing materialPlastic
