OMRON 240990 ZEN-20C2AR-A-V2 small control unit

OMRON 240990 ZEN-20C2AR-A-V2 small control unit

In stock

SKU: 610763

Price on request

€430.09

€0

Overview

Small controller, - basic unit XL, - STINO, 230VAC, 12E+8A(relay), - status LED, no password, - only programmable via software, - IP20

d>56 mm

Property	Value
Number of digital outputs:	8
Number of digital inputs:	12
Supply voltage at AC 50 Hz:	85 to 264 V
Supply voltage at AC 60 Hz:	85 to 264 V
Protection class (IP):	IP20
Switching current:	8 A
Height:	90 mm
Width:	122.5 mm
Depth:
Performance level according to EN ISO 13849-1:	Level a
Category according to EN 954-1:	B
With relay output:	yes
Type of supply voltage:	AC
Expandable:	yes
With timer:	yes
With display:	yes
Wall/direct mounting possible:	yes
Front installation possible:	no
Rail mounting possible:	yes
Rack mounting possible:	no
Wireless standard Bluetooth:	no
Wireless standard WLAN 802.11:	no
Suitable for safety functions:	no
Basic device:	yes
Extension device:	yes
IO-Link Master:	no
With optical interface:	no
Supports protocol for SERCOS:	no
Supports protocol for DeviceNet Safety:	no
Supports protocol for PROFINET IO:	no
Supports protocol for INTERBUS:	no
Supports protocol for AS-Interface Safety at Work:	no
Supports protocol for PROFIBUS:	no
Supports protocol for SafetyBUS p:	no
Supports protocol for PROFIsafe:	no
Supports protocol for data highway:	no
Supports protocol for DeviceNet:	no
Supports protocol for EtherNet/IP:	no
Supports protocol for TCP/IP:	no
Supports protocol for other bus systems:	no
Supports protocol for MODBUS:	no
Supports protocol for SUCONET:	no
Supports protocol for CAN:	no
Supports protocol for ASI:	no
Supports protocol for PROFINET CBA:	no
Supports protocol for KNX:	no
Supports protocol for LON:	no
Supports protocol for Foundation Fieldbus:	no
Supports protocol for INTERBUS-Safety:	no
Number of HW interfaces serial RS-422:	1
Number of HW interfaces serial RS-485:	1
Number of HW interfaces other:	1
Associated equipment (Ex ia):	no
Associated equipment (Ex ib):	no
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Redundancy capability:	no
Radio standard GPRS:	no
SIL according to IEC 61508:	without
Radio standard GSM:	no
Radio standard UMTS:	no

Characteristics

Type of voltage of the supply voltageAC

Supports protocol for KNXNo

With optical interfaceNo

HABZEN-20C2AR-A-V2

Manufacturer

HAN240990

GTIN4547648391238

Width122.5 mm

Explosion protection category for gasWithout

Explosion protection category for dustWithout

Suitable for security functionsNo

Height90 mm

With displayYes

Performance Level according to EN ISO 13849-1Level a

SIL according to IEC 61508Without

IP protection)IP20

Depth56 mm

Mounting rail possibleYes

Supports protocol for AS-Interface Safety at WorkNo

Supports protocol for ASINo

Supports protocol for CANNo

Supports data highway protocolNo

Supports protocol for DeviceNetNo

Supports protocol for DeviceNet SafetyNo

Supports protocol for EtherNet/IPNo

Supports protocol for Foundation FieldbusNo

Supports protocol for INTERBUSNo

Supports protocol for INTERBUS-SafetyNo

Supports protocol for LONNo

Supports protocol for ModbusNo

Supports protocol for PROFIBUSNo

Supports protocol for PROFINET CBANo

Supports protocol for PROFINET IONo

Supports protocol for PROFIsafeNo

Supports protocol for SERCOSNo

Supports protocol for SUCONETNo

Supports protocol for SafetyBUS pNo

Supports protocol for TCP/IPNo

Supports protocol for other bus systemsNo
