OMRON 378891 E3FB-RN11 2M OMI Photoswitch

OMRON 378891 E3FB-RN11 2M OMI Photoswitch

In stock

SKU: 610071

Price on request

€108.89

€0

Overview

Photoelectric sensor, M18, axial, metal case, red LED, retroreflective, 0.1 to 4 m, NPN, L-ON/D-ON selectable, 2 m cable

Feature	Value
Rated sensing distance:	4000 mm
Max. sensing distance:	4000 mm
Min. reflector distance:	100 mm
Max. Output current:	100 mA
Rated control supply voltage Us at DC:	10 to 30 V
Button function:	light/dark switching
Protection class (IP):	IP67
Length of sensor:	44 mm
Diameter of sensor:	18 mm
Reaction time:	0.5 ms
Switching frequency:	1000 Hz
Laser protection class:	without
Type of voltage:	DC
Material of the housing:	metal
With communication interface SSI:	no
With communication interface AS-Interface:	no
With time function:	no
With communication interface DeviceNet:	no
Execution of the switching function:	programmable/configurable
With INTERBUS communication interface:	no
With analog communication interface:	no
With Ethernet communication interface:	no
Analog output 4 mA ... 20 mA:	no
With other analog output:	no
With PROFIBUS communication interface:	no
Reflector included in delivery:	no
Suitable for safety functions:	no
Analog output 0 mA ... 20 mA:	no
Analog output -10 V ... +10 V:	no
With communication interface SSD:	no
With communication interface CANOpen:	no
With communication interface RS-485:	no
Analog output 0 V ... 10 V:	no
Light type:	Red light polarized
Material of the optical surface:	Plastic
With communication interface RS-422:	no
Setting method:	manual setting
With communication interface RS-232:	no
Number of semiconductor outputs with signaling function:	1
Design of the interface for safety-related communication:	other
Design of the electrical Connection:	Cable
Design of the switching output:	NPN
Equipment protection class:	Protection class 0
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Housing design:	Cylinder, thread
Ambient temperature:	-25 to 55 °C
Safety type according to IEC 61496-1:	1
With monitoring function of downstream devices:	no
Pre-failure warning:	no
Wavelength of the sensor:	624 nm
With restart lock:	no
Protection class (NEMA):	other
