Rated operating current Ie at DC-13, 230 V0.4 A
Rated operating current Ie at DC-13, 125 V0.8 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V10 A
HABWLCA12-GN OMR
HAN392927
GTIN4548583485198
Number of contacts as normally open2
Number of contacts as opener2
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementRoller lever adjustable
Design of the electrical connectionCable entry PG
Alignment of the actuatorRoller tappet straight
Rated operating current Ie at AC-15, 230 V10A
Housing coatingPowder coated
Width of the sensor40 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height of the sensor94.1 mm
Length of the sensor67 mm
With status displayNo
Switching functionSnap action contact
Switching function latchingNo
IP protection)IP67
Protection class (NEMA)Other
Ambient temperature during operation-10 to 80 °C
Housing materialMetal
Forced openingNo
