OMRON 404483 E3FA-TN21 OMI photo switch

OMRON 404483 E3FA-TN21 OMI photo switch

In stock

SKU: 610263

Price on request

€106.43

€0

Overview

Optical sensor, cylindrical, PRO, M18 axial, plastic, red LED, through-beam light barrier, 20m, NPN, L-ON/D-ON selectable, M12 connection

Property	Value
Range of the protective field:	20 m
Design of the switching output:	NPN
Rated switching distance:	20000 mm
Rated control supply voltage Us at DC:	10 to 30 V
Max. Output current:	100 mA
Button function:	light/dark switching
Protection class (IP):	IP67
Length of sensor:	45 mm
Width of sensor:	15 mm
Height of sensor:	18 mm
Diameter of sensor:	18 mm
Design of interface for safety-related communication:	other
Explosion protection category for gas:	without
Design of the electrical connection:	M12 connector
Laser protection class:	without
With INTERBUS communication interface:	no
With RS-485 communication interface:	no
With Ethernet communication interface:	no
Reflector included in delivery:	no
Analog output 4 mA ... 20 mA:	no
Housing design:	Cylinder, thread
AWG number:	26
With communication interface SSD:	no
Pre-failure message:	no
With communication interface CANOpen:	no
With restart lock:	no
Analog output -10 V ... +10 V:	no
Material of the housing:	Plastic
Analog output 0 V ... 10 V:	no
Light type:	Red light unpolarized
With analog communication interface:	no
With PROFIBUS communication interface:	no
Design of the switching function:	Normally open (NO)
Safety type according to IEC 61496-1:	1
Explosion protection category for dust:	without
Opening angle:	2 °
Material of the optical surface:	Plastic
Suitable for safety functions:	no
Analog output 0 mA ... 20 mA:	no
Sensor wavelength:	624 nm
Equipment protection class:	Protection class 0
With communication interface RS-422:	no
Max. Switching distance:	20000 mm
Switching frequency:	1000 Hz
With communication interface AS-Interface:	no
Response time:	0.5 ms
With other analog output:	no
With monitoring function of downstream devices:	no
Scope of delivery of the one-way system:	Transmitter and receiver
With communication interface RS-232:	no
Number of semiconductor outputs with signaling function:	1
With communication interface SSI:	no
With communication interface DeviceNet:	no
Cable sheath material:	Polyvinyl chloride (PVC)
Ambient temperature:	-25 to 55 °C
Setting method:	manual setting
Type of voltage:	DC
With Time function:	no
Protection class (NEMA):	other

Characteristics

Diameter of the sensor18 mm

Design of the switching functionNormally open (NO)

Switching frequency1000 Hz

HABE3FA-TN21 OMI

Manufacturer

HAN404483

GTIN4548583440647

Design of the interface for safety-related communicationOther

Design of the switching outputNPN

Design of the electrical connectionConnector M12

Rated control supply voltage Us at DC10 to 30 V

Width of the sensor15 mm

Explosion protection category for gasWithout

Explosion protection category for dustWithout

Suitable for security functionsNo

Housing designCylinder, thread

Height of the sensor18 mm

Length of the sensor45 mm

IP protection)IP67

Protection class (NEMA)Other

Voltage typeDC

Ambient temperature-25 to 55 °C

Housing materialPlastic
