Phoenix Contact 1012268 MCC 0.5/ 4-ST-2.54 PCB connector

In stock
SKU: 603159
€0.40
Into a basketIn the basketGo

Overview

PCB connector, nominal cross section: 0.75 mm², color: black, nominal current: 6 A, rated voltage (III/2): 160 V, contact type: socket (female), number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, article family: MCC 0.5/..-ST, pitch: 2.54 mm, connection type: crimp connection, connection direction conductor/PCB: 0 °, plug-in system: COMBICON FMC 0.5, locking: without, fastening type: without, packaging type: packed in a box

Property Value
Connectable cable type: other
Connectable conductor cross section finely stranded without Wire end ferrule: 0.14 to 0.75 mm²
Number of plug contact rows: 1
Design of the electrical connection: Crimp connection
Rated voltage: 160 V
Rated impulse voltage: 2.5 kV
Rated current In: 6 A
Operating temperature: -40 to 100 °C
Flammability class of the insulating material according to UL 94: V0
Housing color: black
Contact design: Socket
With protective conductor: no
Pitch of connections: 2.54 mm
Pitch of contacts: 2.54 mm
Overvoltage category: III
Pollution degree: 2
Material of the housing: other
Material of the insulating body: other
Angle contact/conductor connection: other
Connection type: other
Number of poles: 4
Housing coating: other

Characteristics

Rated surge voltage2.5 kV
HABMCC0.5/4-ST-2.54
Minimal order250 pcs
ManufacturerPhoenix Contact
HAN1012268
GTIN4055626489216
Design of the electrical connectionCrimp connection
Rated voltage160V
Rated current In6A
Housing coatingOther
Operating temperatur-40 to 100 °C
Flammability class of the insulating material according to UL 94V0
Housing colorBlack
Number of poles4
Connection typeOther
Degree of contamination2
Housing materialOther
Overvoltage categoryIII
Phoenix Contact 1012268 MCC 0.5/ 4-ST-2.54 PCB connector
Phoenix Contact 1012268 MCC 0.5/ 4-ST-2.54 PCB connector
€0.40
