Phoenix Contact 1107441 PST 1,3/ 4-5,0 RD VPE250 pin strip

In stock

SKU: 607756

Price on request

€0.40

€0

Overview

Pin header, nominal cross section: 1.5 mm, color: red, nominal current: 12 A (depending on the plug used), rated voltage (III/2): 320 V, contact surface: tin, contact type: pin (male), number of rows: 1, number of positions per row: 4, article family: PST 1.3/..-V, pitch: 5 mm, assembly: THR soldering, pin layout: linear pinning, pin length [P]: 3.5 mm, plug system: COMBICON COMPACT PST 1.3, locking: without, fastening type: without, packaging type: packed in a box

Property	Value
Number of plug contact rows:	1
Type of Banding:	Cardboard (for SMD)
Type of PCB mounting:	other
Design of electrical connection:	other
Mounting type:	other
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	12 A
Operating temperature:	-40 to 100 °C
Flammability class of the insulating material according to UL 94:	V0
Diameter of the connection pin:	1.3 mm
Housing color:	red
Contact design:	pin
Length of the pin:	3.5 mm
Pitch of the connections:	5 mm
Pitch of the contacts:	5 mm
Connector design:	fixed connector
Overvoltage category:	III
Pollution level:	2
Contact coating material:	tin
Insulating body material:	other
Angle PCB/contact:	other
Connection type:	PCB to cable
