Phoenix Contact 1188920 DFMC 1,5/ 4-STF-3,5 BK LCWH PCB connector

In stock

SKU: 771076

Price on request

€4.59

€0

Overview

PCB connector, nominal cross section: 1.5 mm², color: black, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: tin, contact type: socket (female), number of rows: 2, number of positions per row: 4, article family: DFMC 1.5/..-STF, pitch: 3.5 mm, connection type: push-in spring connection, connection direction conductor/PCB: 0 °, plug system: MINI COMBICON - DFMC 1.5, locking: screw locking, fastening type: screw flange, packaging type: packed in a box

Property	Value
Connectable conductor cross section, single-wire:	0.2 to 1.5 mm²
Connectable conductor cross-section, finely stranded without wire end ferrule:	0.2 to 1.5 mm²
Rated current In:	8 A
Flammability class of the insulating material according to UL 94:	V0
Housing color:	black
Contact design:	socket
With protective conductor:	no
Pitch of the contacts:	3.5 mm
Material of the insulating body:	other
Material of the contact:	copper
