Phoenix Contact 1195484 PC 5/ 6-G-7,62 BK P26 PCB header

In stock

SKU: 770962

Price on request

€4.59

€0

Overview

PCB header, nominal cross-section: 6 mm², color: black, nominal current: 41 A, rated voltage (III/2): 630 V, contact surface: tin, contact type: pin (male), number of rows: 1, number of positions: 6, article family: PC 5/..-G, pitch: 7.62 mm, assembly: wave soldering, pin layout: linear triple pinning, pin length [P]: 2.6 mm, number of soldering pins per potential: 3, plug-in system: COMBICON PC 5, connector face alignment: standard, locking: without, fastening type: without, packaging type: packed in a cardboard box

Property	Value
Number of plug contact rows:	1
Type of Banding:	Cardboard (for SMD)
Type of PCB mounting:	other
Design of electrical connection:	other
Mounting type:	other
Rated voltage:	630 V
Rated impulse voltage:	6 kV
Rated current In:	41 A
Operating temperature:	-40 to 100 °C
Flammability class of the insulating material according to UL 94:	V0
Diameter of the connection pin:	1.3 mm
Housing color:	black
Contact design:	pin
Length of the pin:	2.6 mm
Pitch of the connections:	7.62 mm
Pitch of the contacts:	7.62 mm
Connector design:	fixed connector
Overvoltage category:	III
Pollution level:	2
Contact coating material:	tin
Insulating body material:	other
Angle PCB/contact:	other
Connection type:	PCB to cable
