Phoenix Contact 1252106 MSTB 2,5/12-ST-5,08 BD:13-24 PCB connector

In stock
SKU: 771758
€9.35
Into a basketIn the basketGo

Overview

Printed circuit board connector, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: tin, contact type: socket (female), number of rows: 1, number of poles: 12, article family: MSTB 2.5/..-ST, pitch: 5.08 mm, connection type: screw connection with tension sleeve, screw attack form: L longitudinal slot, connection direction conductor/board: 0 °, locking hook: - locking hook, plug-in system: COMBICON MSTB 2.5, locking: without, fastening type: without, packaging type: packed in a box

Property Value
Connectable cable type: other
Connectable conductor cross section single-wire: 0.2 to 2.5 mm²
Connectable conductor cross-section, stranded with wire end ferrule: 0.25 to 2.5 mm²
Connectable conductor cross-section, stranded without wire end ferrule: 0.2 to 2.5 mm²
Number of plug contact rows: 1
Design of the electrical connection: Screw connection
Rated voltage: 320 V
Rated impulse voltage: 4 kV
Rated current In: 12 A
Operating temperature: -40 to 100 °C
Flammability class of the insulating material according to UL 94: V0
Housing color: green
Contact design: socket
With protective conductor: no
Pitch of the connections: 5.08 mm
Contact pitch: 5.08 mm
Overvoltage category: III
Pollution level: 2
Contact coating material: Tin
Housing material: Other
Insulating body material: Other
Contact material: Copper
Angle contact/conductor connection: other
Connection type: other
Housing coating: other

Characteristics

Rated surge voltage4 kV
HABMSTB 2.5/12-ST-5.08 BD:13-24
Minimal order50 pcs
ManufacturerPhoenix Contact
HAN1252106
GTIN4063151359379
Connectable conductor cross-section solid0.2 to 2.5 mm²
Design of the electrical connectionScrew connection
Rated voltage320V
Rated current In12A
Housing coatingOther
Operating temperatur-40 to 100 °C
Flammability class of the insulating material according to UL 94V0
Housing colorGreen
Connection typeOther
Degree of contamination2
Housing materialOther
Overvoltage categoryIII
