Phoenix Contact 1253122 FMC 1,5/11-ST-3,5 GY PCB connector

Phoenix Contact 1253122 FMC 1,5/11-ST-3,5 GY PCB connector

In stock

SKU: 771881

Price on request

€5.65

€0

Overview

PCB connector, nominal cross section: 1.5 mm, color: gray, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: tin, contact type: socket (female), number of rows: 1, number of positions per row: 11, article family: FMC 1.5/..-ST, pitch: 3.5 mm, connection type: push-in spring connection, connection direction conductor/PCB: 0 °, plug-in system: MINI COMBICON, locking: without, fastening type: without, packaging type: packed in a box

Property	Value
Connectable cable type:	other
Connectable conductor cross section, single-wire:	0.2 to 1.5 mm²
Connectable conductor cross-section, fine-stranded with wire end ferrule:	0.14 to 0.75 mm²
Connectable conductor cross-section, fine-stranded without wire end ferrule:	0.2 to 1.5 mm²
Number of plug contact rows:	1
Design of the electrical connection:	Spring-loaded connection
Rated voltage:	160 V
Rated impulse voltage:	2.5 kV
Rated current In:	8 A
Operating temperature:	-40 to 100 °C
Flammability class of the insulating material according to UL 94:	V0
Housing color:	gray
Contact design:	socket
With protective conductor:	no
Pitch of the connections:	3.5 mm
Pitch of the contacts:	3.5 mm
Overvoltage category:	III
Pollution level:	2
Material of the contact coating:	Tin
Material of the housing:	other
Material of the insulation body:	other
Material of the contact:	copper
Angle contact/conductor connection:	other
Connection type:	other
Housing coating:	other
